Explosion Proof Overhead Crane

Explosion Proof Overhead Crane
  • Explosion Proof Overhead Crane
  • Explosion Proof Overhead Crane
  • Explosion Proof Overhead Crane
  • Explosion Proof Overhead Crane
  • Explosion Proof Overhead Crane
  • Explosion Proof Overhead Crane

Explosion proof overhead crane is evolved on the basis of the LDA model, which features reasonable structure, beautiful appearance, and good explosion-proof performance. It is usually used with HB type and HBS type explosion-proof electric hoist, and it is a light crane.

Specification
Lifting capacity 1-10t
Lifting height 6, 9, 12, 18, 24, 30 m
Span 7.5-22.5 m
Lifting speed 8 8/0.8 m/min
Travelling speed 20 m/min
Working class A3-A5
Working temperature -25~40°C
Power source three-phase 380V 50HZ
Working speed 20 m/min
Features
  • High work efficiency
  • Smooth movement & simple operation
  • Convenient maintenance
  • Light weight and reliable performance
Application

Explosion-proof cranes are especially suitable for inflammable and explosive workshops. The special design enables this crane to run smoothly under special conditions.
