European Standard Overhead Crane

European Standard Overhead Crane
  • European Standard Overhead Crane
  • European Standard Overhead Crane
  • European Standard Overhead Crane
  • European Standard Overhead Crane

European standard overhead crane is designed according to international standards: FEM (Europe), DIN (Germany), ISO (International). It has many advantages such as strong rigidity, light weight, low power, and outstanding structural design. Compared with traditional cranes, European-style cranes have the smallest limit distance from the hook to the wall, the lowest clearance height, and can work closer to the front, with a higher lifting height, which actually increases the effective working space of the existing plant.

Specification
Lifting capacity 1-30ton
Working class A3-A5
Span 7.5-31.5m
Working temperature -25~40°C
Lifting speed 8/0.8m/min
Lifting height 6m, 9m, 12m, 18m, 24m, 30m
Travelling speed 20/30m/min
Features
  • Low headroom and high reliability
  • Smooth operation of material handling
  • Fast lifting and transportation
  • Has intelligent functions to help efficient production
  • Supports synchronous lifting and centralized control
  • The electrical components are of good quality and durable.
Applications

Euro style overhead crane is an ideal choice for workshops, warehouses, material yards, and manufacturing and production facilities. It is suitable for facilities with low headroom and saves space. It is usually used in steel plants, plastic plants, railways, buildings and other places.
